Summary0002647: Speedfan does not detect any fan and GPU + does not detect motherboard temp's + calls cpu temp's Temp1
Description1) Speedfan doesn't detect any fan and therefore also not their proprietary fan speed.

2) Speedfan does not detect the motherboard temperatures.

3) Speedfan does calls the cpu temperatures 'Temp1'.

4) (Minor issue) It calls the M.2 PCIe SSD 'HD1'

5) Does not detect the gpu at all
Additional InformationSystem specs:

Mobo: Biostar X370GTN
Cpu: Ryzen 5 1600X
Ram: G.Skill 3200MHz 16GB
GPU: Palit GTX 1080 Dual OC
Storage: Samsung 960 EVO M.2 PCIe SSD 250GB
         Seagate 2TB SSHD
Tags64-bit, cpu fan, fan, fan speed, mini-itx, TEMP, Temperature
Motherboard ModelBiostar X370GTN
Video Card ModelPalit GTX 1080 Dual OC
